Chemical Compatibility & Media Suitability
Custom fabricated chemical storage tanks and process vessels engineered in dual-laminate thermoplastic and structural FRP by ASK Innocomp.
Operating Temp
-40°C to +120°C
Capacity / Scope
1 KL to 150 KL
Design Standard
Custom CAD / DVS 2205
Testing Protocol
FEA & 20kV Spark Tested
Custom Tailored Vertical & Horizontal Chemical Vessels for Space-Constrained Plants
Engineering Architecture & Construction
1. Application-Specific MOC Selection
We analyze chemical composition, temperature, and specific gravity to specify the exact optimal liner: PVDF, PPH, HDPE, PVC, or pure Vinyl Ester FRP.
2. Precision 3D CAD & FEA Sizing
SolidWorks 3D modeling ensures perfect nozzle orientations, manhole accessibility, internal baffle integration, and structural anchorage.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Capacity Range | 1,000 Litres to 150,000 Litres (1 KL to 150 KL) |
| Construction Types | Vertical Flat/Conical Bottom, Horizontal Dished Ends, Rectangular |
| Material Options | PVDF+FRP, PPH+FRP, HDPE+FRP, PVC+FRP, Vinyl Ester Solid FRP |
| Design Standards | German DVS 2205 / ASME RTP-1 / BS 4994 |
| Accessories Included | Level transmitters, top spiral manholes, lifting lugs, drain sumps |
| Quality Protocol | Finite Element Analysis (FEA) + 100% 20kV Spark Leak Inspection |
Target Industrial Sectors
Chemical Manufacturing
Bulk Raw Material Storage
Bulk Drug & Pharma
Reactant & Solvent Storage
Dyes & Pigments
Slurry Mixing & Neutralization
Effluent Treatment
Heavy Acid Equalization
Automotive
E-Coat & Pre-treatment Lines
Agrochemicals
Pesticide Formulation Tanks
