Chemical Compatibility & Media Suitability
Flame-retardant, non-conductive cable management trays for aggressive chemical plants and coastal environments.
Operating Temp
-40°C to +90°C
Capacity / Scope
50mm to 1000mm Width
Design Standard
NEMA VE-1 / IS 6946
Testing Protocol
Class 1 Fire Retardant
Fire-Retardant Non-Conductive FRP Ladder Type Cable Management Trays
Engineering Architecture & Construction
1. 100% Non-Conductive & Dielectric
Eliminates grounding requirements, electrical eddy currents, and short-circuit hazards near high-voltage industrial cables.
2. Zero Rust & Maintenance Free
Replaces galvanized iron (GI) cable trays in aggressive chemical plants where steel rusts and collapses in under 12 months.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Tray Configurations | Ladder Type, Perforated Type, Solid Bottom Channel Trays |
| Width Options | 50 mm to 1,000 mm (Heights: 50 mm, 75 mm, 100 mm, 150 mm) |
| Standard Length | 3,000 mm (3 Meters) per section |
| Fittings Range | 90° Bends, Horizontal Crosses, Equal/Unequal Tees, Reducers, Couplers |
| Fire Retardancy | Class 1 rating per ASTM E84 (Flame Spread < 25) & Oxygen Index > 30% |
| Hardware Supplied | SS316 splice plates, bolts, nuts, and FRP cover clips |
Target Industrial Sectors
Chemical Refineries
Corrosive Cable Management
Power Plants
High Voltage Cable Support
Chlor-Alkali
Chlorine Gas Atmosphere Trays
Fertilizer Plants
Ammonia & Sulfur Area Trays
Coastal Ports
Salt Spray Resistant Cableways
Water Treatment
Underground Trench Cable Support
