Chemical Compatibility & Media Suitability
High tensile non-metallic, non-corrosive structural reinforcement rebars for chemical plant foundations, marine structures, and dykes.
Operating Temp
-40°C to +80°C
Capacity / Scope
Ø 6mm to Ø 32mm
Design Standard
ACI 440.11-22 / ASTM D7957
Testing Protocol
> 1,000 MPa Tensile
High-Tensile Sand-Coated Structural FRP Rebars for Chemical Concrete Reinforcement
Engineering Architecture & Construction
1. 2x Greater Tensile Strength than Steel
Delivers ultimate tensile strength over 1,000 MPa with only 1/4th the weight of steel, significantly reducing foundation deadweight.
2. 100% Non-Corrosive & Non-Conductive
Impervious to chloride ions, eliminating concrete spalling, rust expansion, and electrical eddy current induction.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Diameter Range | Ø 6 mm, Ø 8 mm, Ø 10 mm, Ø 12 mm, Ø 16 mm, Ø 20 mm, Ø 25 mm, Ø 32 mm |
| Tensile Strength | > 1,000 MPa (Over 2x higher than Grade 60 steel) |
| Modulus of Elasticity | > 50 GPa (Standard Modulus per ACI 440) |
| Surface Coating | Coarse Quartz Sand Coated & Helically Grooved for high concrete bond |
| Service Life | > 100 Years maintenance-free concrete design life |
| Standard Compliance | ACI 440.1R / ASTM D7957 / CSA S807 / IS 18255 |
Target Industrial Sectors
Chemical Storage Dykes
Acid Containment Foundations
ETP & STP Pits
Wastewater Tank Concrete Rebar
Marine & Ports
Seawall & Jetty Construction
Electroplating Plants
Corrosion-Proof Plating Floors
Subway & Rail
TBM Tunnel Soft-Eye Segments
Transformer Yards
Non-Magnetic Substation Slabs
