Chemical Compatibility & Media Suitability
Industrial PVDF and PPH cartridge filter housings and replacement filter elements for aggressive chemical process filtration.
Operating Temp
-20°C to +110°C
Capacity / Scope
Single & Multi-Round
Design Standard
Micron Precision
Testing Protocol
Pressure Rated to 10 Bar
Heavy Industrial PVDF Cartridge Filter Housing with Multi-Round Element Core
Engineering Architecture & Construction
1. Solid PVDF Corrosion-Free Pressure Housing
High-pressure molded PVDF housing provides complete chemical compatibility without metallic contact for corrosive and high-purity fluids.
2. High-Efficiency Sub-Micron Filtration
Accommodates standard 10, 20, 30, and 40 Inch filter cartridges with filtration ratings from 0.1 micron up to 100 microns.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Housing Construction | 100% Solid PVDF (Polyvinylidene Fluoride) / PPH Body |
| Cartridge Lengths | 10 Inch, 20 Inch, 30 Inch, 40 Inch (Single or Multi-Round Core) |
| Filtration Micron Range | 0.1 µm, 0.2 µm, 0.45 µm, 1.0 µm, 5.0 µm, 10 µm, 50 µm, 100 µm |
| Inlet / Outlet Ports | 1 to 3 Inch Flanged / Socket Union Connections |
| Design Pressure | Rated for up to 10 bar (145 psi) working pressure at 25°C |
| Filter Media Types | PVDF Membrane, PTFE Membrane, PPH Melt-Blown, Pleated Microfiber |
Target Industrial Sectors
Electroplating
Continuous Plating Bath Filtration
Semiconductor
High-Purity Acid Chemical Filtration
Pharmaceuticals
Sterile Solvent & Reagent Filtering
PCB Etching
Etchant Solution Clarification
Specialty Chemicals
Product Polishing Filtration
Water Treatment
RO Membrane Pre-Filter Protection
