Chemical Compatibility & Media Suitability
Heavy composite saddle foundations, leg support rings, and structural containment dykes for chemical storage tanks.
Operating Temp
Ambient Industrial
Capacity / Scope
Up to 150 Tons Load
Design Standard
IS 875 / BS 4994
Testing Protocol
Finite Element FEA Rated
Heavy Structural FRP Saddles & Support Rings for Large Chemical Storage Vessels
Engineering Architecture & Construction
1. Zero Rust Foundation Saddles
Engineered composite saddles and base rings eliminate corrosion underneath tanks where moisture and chemical drips accumulate.
2. Optimized Hydraulic Stress Distribution
Precision CNC-contoured saddle curvature provides 120° to 150° support contact with elastomeric pads to prevent localized stress concentration.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Structure Types | Horizontal Tank Saddles, Vertical Leg Rings, Structural Base Skirts, Agitator Bridges |
| Load Capacity | Engineered for vessel operating weights up to 150 Metric Tons |
| MOC Selection | High-Strength Vinyl Ester / Isophthalic Structural Composite Sections |
| Anchorage System | Integrated slotted holes for chemical anchor bolts and thermal expansion clearance |
| Bearing Pads | Supplied with high-durometer EPDM / Neoprene rubber isolation pads |
| Design Validation | SolidWorks Simulation Finite Element Analysis (FEA) certified |
Target Industrial Sectors
Chemical Tank Farms
Heavy Storage Tank Support
Scrubber Installations
Tower Base Anchor Rings
Process Vessels
Agitator Support Bridges
Pickling Plants
Acid Tank Concrete Plinth Protection
ETP Systems
Equalization Tank Saddles
Mining Plants
Slurry Thickener Structures
