Chemical Compatibility & Media Suitability
Vertical cylindrical chemical storage tanks with self-draining conical roofs and flat/sloped bottoms engineered in FRP and dual laminate.
Operating Temp
-20°C to +100°C
Capacity / Scope
1 KL to 100 KL
Design Standard
DVS 2205 / BS 4994
Testing Protocol
100% Spark Tested
Vertical Cylindrical Storage Tank with Self-Draining Conical Roof & Top Nozzles
Engineering Architecture & Construction
1. Rainwater Self-Draining Conical Roof
10° to 15° conical roof pitch prevents liquid pooling and provides high structural rigidity for top manholes and instrumentation brackets.
2. High-Strength Cylindrical Shell
Seamless spiral-wound polymer inner barrel reinforced with circumferential and helical vinyl ester fiberglass filament winding.
Technical Specifications & Design Parameters
| Engineering Parameter | Standard Specification |
|---|---|
| Roof Style | Self-supporting Conical Top with integral stiffening rings |
| Bottom Types | Flat bottom on concrete pad or internal sloped drain sump |
| MOC Options | PVDF+FRP, PPH+FRP, HDPE+FRP, PVC+FRP, Solid Vinyl Ester FRP |
| Standard Dimensions | Diameters from Ø 800 mm to Ø 4,500 mm; Heights up to 12 meters |
| Fittings Included | Flanged inlet/outlet, overflow, drain, level sensor nozzle, top manhole |
| Exterior Protection | UV-stabilized chemical-resistant isophthalic gelcoat (Zero painting needed) |
Target Industrial Sectors
Chemical Plants
Outdoor Bulk Acid Storage
Water Treatment
Coagulant & Disinfectant Storage
Steel & Metal
Acid Recovery Systems
Textile Mills
Bleaching & Dye Liquor Tanks
Pharmaceutical
Process Solvent Containment
Power Plants
Demineralized (DM) Water Tanks
